The ats.js Quickstart Guide

The fastest way to start with the Authenticated Traffic Solution!

Suggest Edits

The ats.js Quick Start Guide provides quick instructions to help you quickly take full advantage of the Authenticated Traffic Solution (ATS).

📘

Implement ATS via Console

The LiveRamp Publisher Console provides an easy-to-use wizard for ATS implementation. Rather than make requests to support or tinker with ATS Javascript directly, use the Console to easily make your desired selections and updates with confidence.

See "Implement ATS via Console" for more information.

The easiest way to use ats.js is with Prebid.js.

This guide walks you through the following tasks:

  • Update Prebid.js
  • Add ats.js
  • Test your installations

1. Update Prebid.js

  1. Visit the Prebid download page and select the following:
  • The latest version of Prebid
  • Adapters that support IdentityLink (such as OpenX, Triplelift or Pubmatic)
  • The User ID: IdentityLink ID module. If you will be processing traffic from the EU/EEA, include Consent Management - GDPR. We recommend, but do not require, that you include Publisher Common ID to provide first-party device identifiers to demand.
  1. Download the newly-compiled prebid.js and replace the old copy.
  2. Update the prebid configuration information.
pbjs.setConfig({
    userSync: {
        userIds: [{
            name: "identityLink",
            params: {
                pid: 'REPLACE_ME'             // Set your real identityLink placement ID here
            },
            storage: {
                type: "cookie",
                name: "idl_env",       // create a cookie with this name
                expires: 7            // cookie can last for seven days
            }
        }],
        syncDelay: 3000              // 3 seconds after the first auction
    }
});
  1. Update the adapter parameters if you're adding new partners.

2. Add ats.js

Add the following tags for ATS at the end of the <body> tag to include and start the library on your site.

<script>
var atsScript = document.createElement('script');
atsScript.onload = function() {
  window.ats.start({
    "placementID": REPLACE_ME,
    "storageType": "localStorage",
    "detectionType": "scrapeAndUrl",
    "urlParameter": "env",
    "cssSelectors": [
      "input[type=text]",
      "input[type=email]"
    ],
    "logging": "error"
  });
};
atsScript.src = 'https://ats.rlcdn.com/ats.js';
document.body.appendChild(atsScript);
</script>

Many more configuration options are available and it's recommended to directly pass user identifiers when possible.

3. Test Your Install End-to-End

Check that ats.js is working

After entering a supported identifier, see if ATS resolved it to an envelope by opening the developer console and running window.ats.retrieveEnvelope();. If an envelope string value is returned, then ats.js is working.

Check that prebid.js is working

  • Reload a prebid-enabled page on your site.
  • Open the developer console and enter pbjs.getUserIds(); to ensure that Prebid returns a LiveRamp identity envelope.
  • Switch to the "Network" tab and see if the envelopes are being pushed to SSPs in ad calls. Pubmatic's POST to https://hbopenbid.pubmatic.com/translator?source=prebid-client, for example, is easy to check, looking for something like the below screenshot:
1520

👍

Congratulations!

You're now taking full advantage of the Authenticated Traffic Solution!
